High Sensitive Decoding OEM Barcode Reader Kiosk Flatbed Barcode Scanner Embedded 1D Laser for Supermarket Project

Availability:

198 in stock

$187.65$201.15

Clear
Compare

High Sensitive Decoding OEM Barcode Reader Kiosk Flatbed Barcode Scanner Embedded 1D Laser for Supermarket Project

Details

1.20lines/5 direction scanning

2.32Bit-CPU

3.Visible laser diode 650nm

4.1500scans/Second

5.RS232,HID USB,KB Interfaces Supported

6.0.127mm(5mil)@Code 93,Minimum

7.Weight:680g

8.Cable Length:2m

9.CE ,ROSH

Features

1)Support both omni-directional and single-line scan

2)20 laser scan line make the scan rate up to 1500 scan/s and 75 scan/s on single-line scan mode omni-directional barcode scanner machine

3)self-developed decoder chip and high performance omni-directional barcode scanner

4)hardware decode technology omni-directional omni-directional barcode scanner

5)Support Keyboard, RS-232, USB interface port.

6)Support more than 20 countries’ keyboard output.

Features

Description

Light source

High performance laser diode 650nm

Beeper Operation

Programmable tone & volume

CPU

32Bit hardware decoder

Scanning mode

20scan lines ,5 directional scanning

Scan type

Omnidirectional and single line scanning

Visual Indicators

Two color LED (blue & red)

Depth of Field

0-220mm for 0.33mm UPC/EAN 100%

Interface

USB.RS232,Keyboard wedge

scanning speed

1500scans/second ,75 scan lines per second- single line

scanning lines

20lines

Minimum resolution

0.127mm(5mil)@Code 39, PCS=90%

Printe contrast

>30%(UPC/EAN 100%)

Physical

Dimemsion

155*150*75mm

weight

680g

cable length

2M

Electrical

Input Voltage

5VDC ± 10%

Operating current

270mA

Standby power?

1.0watts

Safety

Laser Class

CDRH class II,IEC 60825-1 class 1

EMC

CE EN55022 B, FCC Part 15 Class B, VCCI, BSMI

Environmental

Operating temperature

0 ° C~50 ° C(32 ° F-122 ° F)

Operating humidity

5%~95%relative humidity, non-condensing

Storage temperature

20 ° C~+60 ° C(-4 ° F-140 ° F)

Light Levels

4500Lux

Drops

Designed to withstand 1.0m drops

Decode capability

UPC/EAN/JAN, UPC/EAN with supplementary, JAN 8& JAN 13 ISBN/ISSN, EAN,Code

39, Code 39 with full ASCII, Code 93, Code 128,Codabar (NM7),trioptic Code 39,

MSI/Plessy, Interleaved 2 of 5 (ITF), Addendum 2 of 5,IATA Code,China Postal Code,

Code 32, Industrial 2 of 5, Standard 2 of 5,discrete2 of 5,Matrix 2 of 5, Code 11,

UPC/EAN RSS, RSS ariants.
